纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (05-007[02]) - ELEC ASSY, UPP (FOR ANTITHEFT) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
610 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | YN01E01005P1 | [1] | IGNITION KEY | KOBKEY |
| 4. | YN54S00009P1 | [1] | ANTENNA | KOBANTENNA |
| 5. | YN54S01001P1 | [1] | STAY | KOBSTAY |
| 6. | ZS31C03005 | [2] | CAPSCREW | |
| 7. | YT13E01040P2 | [1] | WIRE HARNESS | KOBHARNESS |
| 8. | ZM61C06030 | [1] | BOLT | KOBSEMS |
| 9. | ZW16X06000 | [1] | WASHER | KOB Superseded by part number: 86588450 |
| 11. | YN01E01007P1 | [1] | LABEL | |
| 12. | YN54S00025P2 | [1] | CLUTCH | KOBAMPLIFIER |
| 31. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
