卡特零件查询（730） 150-8240: AXLE & FRAME AR
广数供应链运营团队, 15 02月, 2025，浏览：
337 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | Y | [1] | AXLE AR-FRONT |
| | 148-9959Y | [1] | CYLINDER & MTG GP-STEERING | |
| | 148-9961Y | [1] | CYLINDER & MTG GP-SUSPENSION | |
| | | | S/N AGF1-933 |
| | 210-1886Y | [1] | CYLINDER & MTG GP-SUSPENSION | |
| | | | S/N AGF934-UP |
| | 138-1462Y | [1] | FRAME GP-FRONT | |
| | 139-4720Y | [1] | GEAR GP-OUTPUT TRANSFER | |
| | | | S/N AGF1-449 |
| | 213-3925Y | [1] | GEAR GP-OUTPUT TRANSFER | |
| | | | S/N AGF450-UP |
| | 139-5321Y | [1] | LINES GP-COOLANT | |
| | 148-9963Y | [1] | LINES GP-GREASE(SUSPENSION) | |
| | 186-4062Y | [1] | LINES GP-PRESSURE TEST | |
| | | | S/N AGF1-449 |
| | 168-6867Y | [1] | LINES GP-SUSPENSION | |
| | | | S/N AGF1-933 |
| | 148-9962Y | [1] | MOUNTING GP-TRANSFER GEAR | |
| | | | S/N AGF1-1091 |
| | 250-1725Y | [1] | MOUNTING GP-TRANSFER GEAR | |
| | | | S/N AGF1092-UP |
| | 148-9964Y | [1] | SHAFT GP-FRONT DRIVE | |
| | 148-9960Y | [1] | WIRING GP-FRONT | |
| | | | S/N AGF1-1091 |
| | 229-9726Y | [1] | WIRING GP-MACHINE | |
| | | | S/N AGF1092-UP |
| | Y | | SEPARATE ILLUSTRATION |
