神钢零件查询(K904D) - EXCAVATOR ASN LW5801 (1/84-12/03) (09-011) - BUCKET ASSY, 0.45M3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
384 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2914F1 | [1] | BUCKET ASSY, 0.45M3 | BUCKET ASSY, 0.45M3 |
| . . | 24100N2914F2 | [1] | BUCKET ASSY, 0.45M3 | BUCKET ASSY, 0.45M3 |
| 1. | 2412X362F1 | [1] | BUCKET | |
| 1-1. | 2412X362 | [1] | BUCKET | |
| 1-1P. | 2412U47 | [5] | ADAPTER | KOB |
| 1-1Q. | 2412P304D5 | [1] | EDGE CUTTING | |
| 1-19. | 2405T892 | [4] | BUSHING | KOB |
| 2. | 2412U16F1 | [5] | TOOTH | KOBASSY |
| 2-1. | 2412U16S1 | [5] | BUCKET TOOTH POINT | KOB |
| 2-2. | B12P0015E2 | [5] | PIN | KOB Superseded by part number: 2412Z162K |
| 2-3. | B12P0015E3 | [1] | LOCK PIN | KOBLOCK,RUBBER Superseded by part number: B12P0015E3MK |
| 3. | 2412N278D1 | [1] | BLADE | KOB Superseded by part number: 2412N278D11 |
| 4. | 2412N278D2 | [1] | BLADE | KOB Superseded by part number: 2412N278D21 |
| 5. | R16T0152D3 | [10] | WASHER | KOBFlat -- ID 21 x OD 37 x Th 4.5mm |
| 6. | ZS13F20055 | [10] | SCREW | KOBM20x1.50x55mm |
| 7. | ZN13F20016 | [10] | NUT | KOBM20x1.50mm |
| 8. | 2445Z887 | [4] | O-RING | KOBID 104.5 ± 0.40 x OD 123.1mm |
| 9. | 2412X375F1 | [1] | BUCKET, 0.45M3 | |
| 9-1. | 2412X362 | [1] | BUCKET | |
| 9-1P. | 2412U47 | [5] | ADAPTER | KOB |
| 9-1Q. | 2412P525D5 | [1] | EDGE, CUTTING | |
| 9-19. | 2405T892 | [4] | BUSHING | KOB |
