纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-033) - MIRROR INSTAL, P/N YY52C00003F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
299 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY52C00003F1 | [1] | MIRROR | KOBINSTAL |
| A1. | YY52C01007P1 | [1] | STAY | KOBSTAY |
| A2. | YY52C01003P1 | [1] | CLAMP | KOB |
| A3. | 2456Z253 | [1] | MIRROR | KOBBACK |
| A4. | YY52C01006P1 | [1] | SUPPORT | KOB |
| A5. | ZS18C08045 | [2] | SCREW,Hex, M8 x 45mm | KOBCAP |
| A6. | ZW26X08000 | [2] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| A7. | ZN18C12010 | [2] | NUT | KOB |
| A8. | ZW16X12000 | [2] | WASHER | KOB |
| A9. | R16T0137D1 | [4] | WASHER | KOB |
| A10. | ZW16X08000 | [2] | WASHER | KOB |
| . . | YT52C00008F3 | [1] | MIRROR | KOBINSTAL (STD/WITH ROOF & TRIPLE GUARD/LIGHT) |
| . . | YT52C00008F4 | [1] | MIRROR | KOBINSTAL (WITH FRONT UPP GUARD) |
| B2. | YY02C01004P1 | [1] | STAY | KOBSTAY |
| B7. | YY02C01001P1 | [1] | PLATE | KOBASSY, (FOR F3 ONLY) |
| B8. | ZS18C10045 | [2] | SCREW,Hex, M10 x 45mm | KOBCAP, (FOR F3 ONLY) |
| B9. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm, (For F3 Only) |
| B10. | ZW16H10000 | [2] | WASHER | KOB(FOR F3 ONLY) |
| B11. | YN02C01121P1 | [1] | MIRROR | KOB |
| B12. | ZM46C05016 | [3] | BOLT,Phillip, M5 x 0.8 x 15mm | KOBSEMS |
| B13. | YT50C01077P1 | [1] | BLOCK | KOBTAPPED |
