纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-035) - CAB INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
290 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN02C00031F1 | [1] | CAB INSTAL | |
| A1. | ZS18C10025 | [5] | SCREW,Hex, M10 x 25mm | KOB |
| A2. | ZW26X10000 | [5] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| A3. | ZW16H10000 | [5] | WASHER | KOB |
| A4. | YT54C00003F1 | [1] | TANK | KOBASSY, WATER |
| A4-1. | YT54C00003S001 | [1] | ELECTRIC MOTOR | KOBSSY |
| A4-2. | YT54C00003S002 | [1] | TANK | KOBASSY, WATER |
| A4-3. | YT54C00003S003 | [1] | BRACKET | KOB Superseded by part number: 2416P7292 |
| A5. | ZM61C06016 | [2] | BOLT | KOBSEMS |
| A6. | YT02C01126D5 | [1] | TUBE | KOB Superseded by part number: YT02C01126D6 |
| A7. | YT02C01282P1 | [1] | ELEC CONNECTOR | KOB |
| A8. | YN03M01159P1 | [1] | GROMMET | KOB |
| . . | YF02C00003F2 | [1] | CAB ASSY (WITH POWER WINDOW) | |
| B1. | YF02C00004P1 | [1] | CAB ASSY | |
| B2. | YN02C00076F1 | [1] | CAB | KOBASSY, (FOR F1 ONLY), SEE FIG 01-037 Superseded by part number: YN02C00076F1%K1 |
