纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-044) - GUARD INSTAL (COUNTERWEIGHT) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
493 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF21C00001FD | [1] | GUARD INSTAL | |
| 2. | YB21C01075F1 | [1] | COVER | KOBASSY Superseded by part number: YB21C01075F3 |
| 2-1. | YN21C01610P2 | [1] | COVER | KOB |
| 8. | ZM32C12025 | [2] | BOLT | KOBSEMS |
| 9. | HS18C10025G1 | [4] | SCREW | KOBCAP Superseded by part number: ZS18C10025 |
| 10. | HY25X11024G1 | [4] | WASHER | KOB |
| 11. | YT21C01172P1 | [4] | LOCK WASHER | KOB |
| 12. | YT21C01187P2 | [4] | WASHER | KOB |
| 19-2. | PM21C01109P1 | [1] | LOCK | KOB |
| 19-3. | PM21C01268F1 | [1] | LOCK | KOBASSY |
| 19-3A. | YR22C01025P1 | [1] | LOCK | KOB Superseded by part number: YR22C01025P2 |
| 19-3F. | PM21C01269P1 | [1] | PLATE | KOB |
| 19-4. | ZN18C05004 | [6] | NUT | KOB |
| 19-5. | ZW26X05000 | [4] | LOCK WASHER | KOBLOCK |
| 19-6. | PH22C01023P1 | [4] | BOLT | KOB |
| 19-7. | 2416T6682 | [2] | RUBBER BAND | KOBCUSHION |
| 19-11. | YF21C01004P1 | [1] | STAY | KOBSTAY |
| 19-12. | ZW16X08000 | [1] | WASHER | KOB |
| 19-13. | 2419R9D2 | [1] | COTTER PIN | KOBSNAP |
| 19-14. | YR21C01123P1 | [1] | COLLAR | KOB |
| 19-19. | ZM32C10025 | [6] | BOLT | KOBSEMS |
| 19-24AC. | YT21C01027P1 | [2] | HINGE | KOB |
