纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-045) - COVER ASSY, UNDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
329 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF24C00002F1 | [1] | COVER ASSY, UNDER | |
| A3-3. | 2427P1836D20 | [1] | WEATHERSTRIP | KOB |
| A3-4. | YT21C01297D2 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| A13. | ZS18C12035 | [41] | SCREW,Hex, M12 x 35mm | KOBCAP |
| A14. | ZW26X12000 | [41] | WASHER | KOB |
| A15. | ZW16H12000 | [41] | WASHER | KOB |
| B1. | 2416T13049D6 | [15] | BLOCK | KOBTAPPED |
| B2. | 2416T13049D8 | [2] | U-BRACKET | KOBBLOCK, TAPPED |
| B3. | YN52F01241P1 | [7] | ANGLE | KOB |
| B4. | YF52F01012P1 | [1] | PLATE | |
| B5. | YF52F01013P1 | [1] | PLATE | |
