纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-003-00[01]) - ENGINE MOUNTING - ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
554 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUH0199 | [1] | ENGINE ASSEMBLY | ISUENGINE ASSY |
| . . | KTH0537 | [1] | CONTROL | SUM |
| 2. | KUH0149 | [1] | ENGINE MOUNT | SUM |
| 3. | KUH0150 | [1] | ENGINE MOUNT | SUM |
| 4. | 166470A1 | [8] | BOLT,M14, W/ Wshr | SUM |
| 5. | KUH0115 | [4] | SILENTBLOC | SUM |
| 6. | KUH0013 | [2] | PLATE | SUM |
| 7. | 102R024Y200R | [2] | BOLT | SUMM24 x 200 |
| 8. | 150822A1 | [4] | WASHER,25mm ID x 48mm OD x 6mm Thk | SUMM24 |
| 9. | 829-1424 | [2] | NUT,M24, Cl 10 | CAS Superseded by part number: 9848973, 87778058 |
| 10. | KUH10020 | [1] | FLANGE | SUM |
| 11. | 827-12085 | [12] | BOLT,Hex, M12 x 1.75 x 85mm, Cl 10.9 | SUMM12 x 85; 10.9 Superseded by part number: 86979023 |
| 12. | 150811A1 | [12] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 13. | KUH0114 | [4] | SILENTBLOC | SUM Superseded by part number: KUH10370 |
| 14. | KUH0152 | [2] | SPACER | SUM |
| 16. | KUH0151 | [2] | BOLT | SUMM24 x 330 |
| 19. | KUH0153 | [1] | STEP | SUM |
| 20. | KMH0201 | [2] | BOLT | SUMM10 x 30 |
| 21. | 150409A1 | [2] | WASHER | SUM10,5 x 21 x 3,2 mm |
| 22. | 895-11008 | [2] | WASHER,M8 x 16 x 1.6 | CAS9 x 17 x 1,6 mm Superseded by part number: 86624184 |
| 23. | 183-108VR | [2] | SPRING WASHER | SUMW8 |
| 24. | 829-1408 | [2] | NUT,Hex, M8 x 1.25, Cl 10.9 | CAS Superseded by part number: 43362, 87778059 |
