纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-005-00[01]) - AIR FILTRATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
459 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUH0010 | [1] | FILTER ASSY | SUM |
| 2. | KUH0024 | [1] | AIR CLEANER | SUM |
| 3. | KUH0027 | [2] | FIXING STRIP | SUM |
| 4. | 166052A1 | [4] | BOLT | SUM Superseded by part number: 11106231 |
| 5. | KSH0050 | [1] | INDICATOR | SUM |
| 6. | KRH1236 | [1] | SEAL | SUM |
| 7. | KRH1237 | [1] | ELBOW | SUM |
| 8. | 167850A1 | [1] | HOSE | SUM Superseded by part number: KHH14430 |
| 9. | 165951A1 | [2] | CLAMP | SUM |
| 10. | KHR2787 | [1] | CLAMP | SUM |
| 11. | KUH0167 | [1] | AIR FLEXIBLE | SUM |
| 12. | 158840A1 | [1] | BAND,133mm - 158mm | SUM |
| 13. | 150855A1 | [1] | HOSE CLAMP,127mm - 146mm | SUM |
| 14. | KUH0168 | [1] | AIR INTAKE TUBE,123 mm ID x 127 mm OD | SUM |
| 15. | 166352A1 | [2] | BOLT | SUM |
| 16. | KTH0531 | [1] | AIR FLEXIBLE | SUM |
| 17. | 150545A1 | [1] | COLLAR | SUM |
| 18. | 150294A1 | [1] | CLAMP,95mm - 115mm | SUM |
| 19. | KUH0057 | [1] | AIR FLEXIBLE | SUM |
| 20. | KSJ2139 | [2] | FIXING STRIP | SUM |
| 21. | KUH0072 | [1] | AIR INTAKE TUBE | SUM |
| 23. | KUH0060 | [1] | SEAL | SUM |
| 24. | KUH0025 | [1] | AIR FILTER | SUM |
| 25. | KUH0026 | [1] | AIR FILTER | SUM |
