神钢零件查询(ED150) - BLADE RUNNER EXCAVATOR/DOZER BTW YL04-00501 - YL04-00554 (4/03-10/03) (01-003) - ENGINE ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
418 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY02P00006F2 | [1] | ENGINE | KOBASSY |
| 2. | YX05P01031P1 | [1] | RADIATOR HOSE | KOBRADIATOR |
| 3. | YX05P01030P1 | [1] | RADIATOR HOSE | KOBRADIATOR |
| 4. | YT52S00001P1 | [1] | SENSOR,50 Degrees C to 120 Degrees C | KOBCoolant Temperature (Thermo) Superseded by part number: YN52S00077F1 |
| 5. | YX20M01025P1 | [1] | V-BELT,42.92" L | KOB(Conditioner, Air) Superseded by part number: 84214719 |
| 6. | VI8971256010 | [1] | SWITCH | KOBTHERMO Superseded by part number: 289737A1 |
| 7. | VI8944147963 | [1] | ELEMENT | KOBFUEL Superseded by part number: EN02P00001-2 |
| 8. | VI8970261342 | [1] | FILTER | KOBELEMENT, OIL (BY-PASS) Superseded by part number: 84160436 |
| 9. | VI8941609641 | [1] | ELEMENT | KOBFILTER, OIL (FULL FLOW) Superseded by part number: 2451U309-1 |
| 10. | VI8972186470 | [1] | OIL SEPARATOR | KOBWATER |
| 11. | VI1137700700 | [1] | THERMOSTAT | KOB |
| 12. | VI8970298634 | [1] | STATOR | KOBSTARTER ASSY Superseded by part number: 289709A1 |
| 13. | VI1812004710 | [1] | ALTERNATOR | KOBALTERNATOR ASSY |
| 14. | VI1824100082 | [1] | SWITCH | KOBOIL Superseded by part number: 76554707 |
| 15. | VI1136712260 | [1] | BELT | KOBV Superseded by part number: VI8972322520 |
| 16. | VI8943690210 | [1] | GASKET | KOB(EXHAUST) |
| 18. | VI8942580140 | [1] | RELAY | KOBGLOW Superseded by part number: VI8944233140 |
| 19. | VI1815105130 | [1] | SENSOR | KOBREVOLUTION |
