纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-025-00[01]) - TURBOCHARGER - EXHAUST PIPE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
169 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 426255A1 | [1] | TURBOCHARGER | ISU |
| 2. | 426256A1 | [1] | MANIFOLD GASKET | ISU |
| 9. | 426257A1 | [1] | MANIFOLD GASKET | ISU |
| 10. | 426259A1 | [6] | WASHER | ISU |
| 11A. | 289065A1 | [6] | NUT | ISU |
| 11B. | 426260A1 | [8] | NUT | ISUM10 Superseded by part number: 71455342 |
| 12. | 426261A1 | [6] | STUD | ISUM12 x 135 Superseded by part number: 71456086 |
| 16. | 426262A1 | [1] | ADAPTER | ISU |
| 29. | 443710A1 | [1] | SUPPORT | ISU |
| 66. | 426263A1 | [4] | STUD | ISU |
