纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-027-00[01]) - TURBOCHARGER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
491 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 426255A1 | [1] | TURBOCHARGER | ISU |
| 1. | 433686A1 | [1] | HOUSING | ISU |
| 2. | 433687A1 | [1] | IMPELLER | ISU |
| 3. | 433688A1 | [1] | HOUSING | ISU |
| 5. | 433689A1 | [1] | PROTECTOR | ISU |
| 6. | 433690A1 | [1] | SHAFT | ISU |
| 7. | 433691A1 | [1] | HOUSING | ISU |
| 10. | 86992278 | [1] | REPAIR KIT | ISUOverhaul |
| 12. | 433693A1 | [1] | NUT | ISU |
| 17. | 433694A1 | [4] | GUIDE RING | ISU |
| 18. | 433695A1 | [4] | SCREW | ISU |
| 20. | 433696A1 | [1] | THRUST RING | ISU Superseded by part number: 433840A1 |
| 21. | 433697A1 | [1] | SPECIAL BOLT | ISU |
| 22. | 433698A1 | [1] | SEALING RING | ISUSEALRING |
| 23. | 433699A1 | [1] | SEALING RING | ISUSEALRING |
| 24. | 433700A1 | [1] | SEALING RING | ISUSEALRING |
| 25. | NSS | [1] | NOT SERVICED SEPARATELY | CONBushing |
| 36. | 433701A1 | [10] | BOLT | ISU |
| 37. | 433702A1 | [10] | PLATE | ISU |
| 41. | 433703A1 | [8] | PLATE | ISU |
| 42. | 433704A1 | [8] | BOLT | ISU |
| 44. | 433705A1 | [1] | SEAL | ISU |
| 45. | 433706A1 | [4] | SCREW | ISU |
