纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-039-00[01]) - OIL CIRCUIT - ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
895 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 443833A1 | [1] | INJECTION PIPE | ISU |
| 2. | 426634A1 | [1] | PIPE ASSY. | ISU |
| 3. | 426635A1 | [2] | BOLT | ISUM10 x 21 |
| 4. | 289104A1 | [2] | BANJO BOLT | ISU Superseded by part number: 1096750860 |
| 5. | 426641A1 | [1] | BOLT | ISUM18 x 26 |
| 6. | 426642A1 | [1] | BOLT | ISUM12 x 27 Superseded by part number: 84164363 |
| 7. | 289093A1 | [2] | PACKING | ISU |
| 8. | 426472A1 | [2] | GASKET,18.2mm ID x 24.4mm OD | ISU18,2 ID x 24,4 OD |
| 9. | 426423A1 | [4] | GASKET | ISU14,2 ID x 19,2 OD Superseded by part number: 289094A1 |
| 40. | 426208A1 | [4] | BOLT | ISUM10 x 30 |
| 44. | 419935A1 | [1] | BOLT | ISUM8 x 16 Superseded by part number: 76599954 |
| 48. | 426643A1 | [1] | MOUNTING CLIP | ISU |
| 63. | 426644A1 | [1] | PIPE ASSY. | ISU |
| 114. | 426645A1 | [1] | PIPE ASSY. | ISU Superseded by part number: 72110504 |
| 117. | 289092A1 | [4] | GASKET | ISU |
| 132. | 426646A1 | [1] | PIPE ASSY. | ISU |
| 144. | 426415A1 | [2] | CLIP | ISU |
| 145. | 426275A1 | [1] | BOLT | ISUM10 x 16 Superseded by part number: 87597950 |
| 146. | 426647A1 | [1] | GASKET | ISU10,8 ID Superseded by part number: 71455994 |
| 147. | 426648A1 | [1] | GASKET | ISU27,7 ID |
| 148. | 288544A1 | [2] | SPECIAL BOLT | ISUM10 x 35 Superseded by part number: 87577258 |
| 149. | 426649A1 | [1] | PIPE ASSY. | ISU |
| 157. | 426650A1 | [1] | SUPPORT | ISU |
| 251. | 426651A1 | [1] | BOLT | ISUM6 x 35 |
| 396. | 443834A1 | [1] | RUBBER SLEEVE | ISU |
