神钢零件查询(ED150) - BLADE RUNNER EXCAVATOR/DOZER BTW YL04-00501 - YL04-00554 (4/03-10/03) (01-032) - MIRROR INSTAL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
752 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY52C00001F1 | [1] | MIRROR | KOBINSTAL |
| A1. | PY02C01079P1 | [1] | MIRROR | KOBBACK |
| A2. | YY02C01004P1 | [1] | STAY | KOBSTAY |
| A3. | ZN18C12010 | [4] | NUT | KOBM12x1.75mm |
| A4. | ZW16X12000 | [2] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| A5. | R16T0137D1 | [2] | WASHER | KOBCone Disk Spring -- ID 12.2 x OD 25 x Th 0.9mm |
| A7. | YY02C01001P1 | [1] | PLATE | KOBASSY |
| A8. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| A9. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| A10. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| A11. | YN02C01121P1 | [1] | MIRROR | KOB |
| A12. | ZM46C05016 | [3] | BOLT,Phillip, M5 x 0.8 x 15mm | KOBM05x0.8x16mm (Incls. Washer & Lockwasher) |
| A13. | YT50C01077P1 | [1] | BLOCK | KOBTAPPED |
| . . | YY52C00003F1 | [1] | MIRROR | KOBINSTAL |
| B1. | YY52C01007P1 | [1] | STAY | KOBSTAY |
| B2. | YY52C01003P1 | [1] | CLAMP | KOB |
| B3. | 2456Z253 | [1] | MIRROR | KOBBACK |
| B4. | YY52C01006P1 | [1] | SUPPORT | KOB |
| B5. | ZS18C08045 | [2] | SCREW,Hex, M8 x 45mm | KOBM08x1.25x45mm |
| B6. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| B7. | ZN18C12010 | [2] | NUT | KOBM12x1.75mm |
| B8. | ZW16X12000 | [2] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| B9. | R16T0137D1 | [4] | WASHER | KOBCone Disk Spring -- ID 12.2 x OD 25 x Th 0.9mm |
| B10. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
