纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-053-00[01]) - CYLINDER BLOCK New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
852 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 288577A1 | [1] | SKELETON ENGINE | ISU |
| 2. | 288578A1 | [6] | SLEEVE ASSY | ISUGrade 1 Superseded by part number: 76615592 |
| 2. | 288579A1 | [6] | SLEEVE ASSY | ISUGrade 3 Superseded by part number: 76615647 |
| 4. | 288580A1 | [6] | SLEEVE CYLINDER | ISUGrade 1 Superseded by part number: 76615593 |
| 4. | 288581A1 | [6] | SLEEVE CYLINDER | ISUGrade 3 |
| 30. | 289771A1 | [3] | PIN | ISU |
| 32. | 288582A1 | [2] | DOWEL | ISU |
| 34. | 288571A1 | [1] | VALVE, PRESSURE RELI | ISUEF |
| 35. | 288583A1 | [2] | GASKET | ISU Superseded by part number: 71455212 |
| 36. | 289074A1 | [4] | CUP | ISUdia 45 Superseded by part number: 71455047 |
| 37. | 289076A1 | [1] | CUP | ISUdia 25 |
| 38. | 288584A1 | [2] | PLUG | ISU40 OD Superseded by part number: 72110192 |
| 39. | 288553A1 | [13] | PLUG | ISU40 OD |
| 46. | 288585A1 | [6] | BOLT | ISU |
| 56. | 288586A1 | [1] | LUBE OIL NOZZLE | ISULUBE OIL JET NOZZLE Superseded by part number: 72110194 |
| 70. | 426423A1 | [4] | GASKET | ISU Superseded by part number: 289094A1 |
| 83. | 288587A1 | [2] | PIN | ISU |
| 122. | 288588A1 | [1] | ADAPTER | ISU |
| 210. | 288589A1 | [14] | BOLT | ISUM18 x 150 |
| 211. | 288590A1 | [28] | BOLT | ISUM12 x 114 |
| 212. | 288591A1 | [2] | PIN | ISU |
| 218. | 289092A1 | [1] | GASKET | ISU |
| 219. | 289093A1 | [1] | PACKING | ISU |
| 220. | 288592A1 | [1] | GASKET | ISU22 OD Superseded by part number: 72110199 |
| 221. | 288565A1 | [2] | GASKET | ISU Superseded by part number: 72110175 |
| 230. | 288593A1 | [2] | PIN | ISU |
| 231. | 288594A1 | [2] | PIN | ISU5 OD |
| 335. | 288595A1 | [1] | PLUG | ISUM22 x 12 |
| 336. | 288569A1 | [1] | PLUG | ISUM10 x 7 |
| 337. | 288596A1 | [1] | PLUG | ISUM12 x 9 |
| 338. | 289998A1 | [1] | PLUG | ISU |
| 479. | 288597A1 | [1] | PLUG | ISU |
