纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-057-00[01]) - PISTONS AND CRANKSHAFT - FLYWHEEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
832 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 419801A1 | [1] | CRANKSHAFT | ISU Superseded by part number: 72110251 |
| 7. | 288923A1 | [1] | CRANKSHAFT BEARING | ISU |
| 12. | 419821A1 | [1] | FLYWHEEL | ISU |
| 18. | 419823A1 | [1] | PULLEY | ISU Superseded by part number: 87644907, 71456307, 87644902 |
| 20. | 419824A1 | [1] | DAMPER | ISU |
| 22. | 419825A1 | [4] | WASHER | ISU18 ID |
| 23. | 419826A1 | [1] | WASHER | ISU18 ID |
| 24. | 419827A1 | [8] | BOLT | ISUM12 x 30 |
| 28. | 419829A1 | [1] | GEAR | ISU48 Z Superseded by part number: 84187990 |
| 32. | 289770A1 | [1] | PIN | ISU8 OD |
| 34. | 419830A1 | [1] | SMALL PIN | ISU5 OD |
| 35. | 419831A1 | [1] | RING, FLYWHEEL | ISU Superseded by part number: 71455913 |
| 38. | 419832A1 | [1] | WASHER | ISU |
| 40. | 419833A1 | [10] | BOLT | ISU Superseded by part number: 71455915 |
| 42. | 419842A1 | [2] | THRUST WASHER | ISU |
| 63. | 419820A1 | [6] | PISTON | ISU Superseded by part number: 76615981 |
| 68. | 419822A1 | [6] | PISTON RINGS KIT | ISU |
| 73. | 419834A1 | [6] | SET OF CONN ROD BRGS U/S | ISU |
| 83. | 419835A1 | [6] | PISTON PIN | ISU |
| 84. | 419836A1 | [6] | PITMAN ASSY. | ISU |
| 85. | 419837A1 | [1] | BUSHING | ISU Superseded by part number: 72110267 |
| 86. | 419838A1 | [2] | BOLT | ISU |
| 88. | 419839A1 | [2] | NUT | ISU |
| 126. | 419840A1 | [12] | SNAP RING | ISU Superseded by part number: 72110270 |
| 149. | 419841A1 | [6] | PLUG | ISU |
