纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-059-00[01]) - AIR COMPRESSOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
574 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 426265A1 | [1] | GASKET | ISU |
| 3. | 426266A1 | [1] | KEY | ISU |
| 4. | 426267A1 | [1] | BOLT | ISUM14 x 128 |
| 5. | 426269A1 | [1] | BOLT | ISUM14 x 90 |
| 5. | 419939A1 | [1] | BOLT | ISUM14 x 100 Superseded by part number: 84256290 |
| 6. | 426270A1 | [1] | NUT | ISUM14 Superseded by part number: 84477146 |
| 8. | 289796A1 | [3] | WASHER | ISU14 ID |
| 19. | 426271A1 | [1] | PINION | ISU54 Z |
| 20. | 426272A1 | [5] | BOLT | ISUM12 x 39 |
| 24. | 426273A1 | [1] | POINTER | ISU |
| 39. | 426264A1 | [1] | COMPRESSOR | ISU |
| 176. | 426274A1 | [1] | BOLT | ISUM10 x 16 |
| 211. | 426275A1 | [2] | BOLT | ISUM10 x 16 Superseded by part number: 87597950 |
| 213. | 426276A1 | [1] | SPLIT PIN/SAFETY PIN | ISU |
| 233. | 426277A1 | [1] | CIRCLIP | ISU |
