纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (03-003-00[01]) - FUEL TANK New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
958 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUH0118 | [1] | FUEL TANK | SUM |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CONTank, Fuel |
| 3. | 150492A1 | [1] | LOCKABLE FUEL CAP | SUM |
| 4. | 163804A1 | [1] | GASKET | SUM |
| 5. | KHH0330 | [1] | GAUGE | SUM Superseded by part number: KHH0500 |
| 6. | 150146A1 | [1] | FILTER | SUM Superseded by part number: KHH0500 |
| 7. | 151322A1 | [1] | GASKET,3mm Thk | SUM |
| 8. | 151320A1 | [1] | COVER | SUM |
| 9. | 166052A1 | [8] | BOLT | SUM Superseded by part number: 11106231 |
| 10. | 150847A1 | [1] | HYD CONNECTOR | SUM |
| 11. | 158923A1 | [1] | DRAIN VALVE | SUM |
| 12. | 102R020Y090R | [8] | BOLT | SUMM20 x 90 |
| 13. | KUJ0017 | [8] | SPACER | SUM |
| 14. | 153208A1 | [8] | SHIM | SUM |
| 15. | 153209A1 | [8] | SHIM | SUM |
| 16. | KHR2262 | [1] | SENSOR | SUM |
| 17. | 159698A1 | [1] | COVER | SUM |
| 18. | 151688A1 | [5] | SCREW,Phil Pan Hd, M5 x 12mm, W/ Wshr | CAS |
| 19. | 152591A1 | [1] | GASKET,2mm Thk | SUM |
