神钢零件查询(ED150) - BLADE RUNNER EXCAVATOR/DOZER BTW YL04-00501 - YL04-00554 (4/03-10/03) (01-036) - DOOR ASSEMBLY, CAB Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
459 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT51C00003F2 | [1] | DOOR ASSY. | KOBCAB Superseded by part number: YT51C00003F2%K1 |
| 2. | YT51C01011P1 | [1] | HANDLE | KOB |
| 3. | YT51C01053P1 | [1] | HANDLE | KOB |
| 4. | YT51C01023P1 | [1] | HOOK | KOB |
| 5. | YT51C01078P1 | [1] | GLASS | KOB |
| 6. | YT02C01074P1 | [1] | GLASS | KOB |
| 7. | YT51C01079P1 | [1] | GLASS | KOB |
| 8. | YT51C01024F1 | [1] | LOCK ASSY | KOB Superseded by part number: YT51C01024F1M |
| 9. | YT51C01045P1 | [1] | SEAL | KOB |
| 10. | YT51C01046P2 | [1] | SEAL | KOB |
| 11. | YT02C01117P1 | [1] | SEAL | KOB |
| 12. | YT51C01065D1 | [2] | PLATE | KOB |
| 13. | YT02C01261D2 | [2] | PLATE | KOB |
| 14. | YT02C01233P1 | [2] | CAP | KOB |
| 15. | YT02C01295D1 | [1] | RUBBER SLEEVE | KOB |
| 16. | YT51C01047P1 | [1] | COVER | KOB |
| 17. | YT51C01050F1 | [1] | PLATE ASSY. | KOB |
| 17-1. | YT51C01051P1 | [1] | PLATE ASSY. | KOB Superseded by part number: YT51C01050F1 |
| 17-2. | YT01T01004D1 | [2] | DECAL | KOB |
| 18. | YT51C01039P1 | [1] | GROMMET | KOB |
| 19. | YT51C01020P1 | [1] | LOCK ASSY | KOB Superseded by part number: YT51C01020P2 |
| 20. | YT51C01060F1 | [1] | LOCK ASSY | KOB |
| 20-1. | YT51C01027P1 | [1] | LOCK | KOB |
| 20-2. | YT51C01044F1 | [1] | ROD | KOB |
| 20-2A. | YT51C01044S001 | [1] | BAR | KOB |
| 20-2B. | YT51C01017P1 | [1] | PIN | KOB |
| 20-2C. | YT51C01043P1 | [1] | NUT | KOB |
| 20-3. | YT51C01016P1 | [1] | PIN | KOB |
| 21. | YT51C01061F1 | [1] | HANDLE | KOB Superseded by part number: YT51C01084F1 |
| 21-1. | YT51C01048P1 | [1] | HANDLE | KOB Superseded by part number: YT51C01084F1 |
| 21-2. | YT51C01018P1 | [1] | HOLDER | KOB |
| 21-3. | YR02C01480P1 | [1] | SPRING | KOB |
| 22. | YT51C01029P1 | [1] | CLIP | KOB40x33x3.7mm |
| 23. | YT51C01014P1 | [1] | ROD | KOB |
| 24. | YR02C01485P1 | [1] | HOLDER | KOB Superseded by part number: YR02C01485P2 |
| 25. | YT51C01042P1 | [1] | GRIP | KOB |
| 26. | HN16C06000G1 | [2] | NUT | KOBM06x1.0mm |
| 27. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| 28. | YT51C01068P1 | [2] | WASHER | KOBID 08.1 x OD 15.5 x Th 2.5mm |
| 29. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 30. | YT51C01058D1 | [2] | SCREW | KOB |
| 31. | ZM27C10025 | [2] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) |
| 32. | YT02C01296P1 | [2] | RIVET | KOB |
| 33. | ZM66C06016 | [2] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 34. | ZS41C06016 | [3] | SCREW,M6 x 16mm | KOBM06x1.0x16mm |
| 35. | YT02C01230P1 | [3] | WASHER,6.4mm ID x 12mm OD x 0.5mm Thk | KOBStar Lock -- ID 06.40 ± 0.30 x OD 12 x Th 0.5mm |
| 36. | YT51C01018P1 | [1] | HOLDER | KOB |
| 37. | YT51C01074P1 | [1] | PANEL | KOB |
| 38. | YT51C01081D1 | [1] | SEAL | KOB |
| 39. | YT02C01514D2 | [1] | SEAL | KOB Superseded by part number: YR02C01511D2 |
| 40. | YR01T01005P1 | [2] | ADHESIVE | KOB Superseded by part number: YN01T01067P1 |
| 41. | YR09T00002P1 | [2] | PAINT | KOB Superseded by part number: YN09T00009P1 |
| 42. | YR09T00003P1 | [2] | PAINT | KOB |
| 44. | PE21C01070DC | [1] | TRIM PANEL | KOB |
| 45. | YT02C01515D1 | [1] | TRIM PANEL | KOB Superseded by part number: YT02C01515D2 |
