纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (03-009-00[01]) - FUEL FILLING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
173 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | KUR0018 | [1] | PUMP, HYDRAULIC | SUM |
| 3. | 166192A1 | [1] | FILTER STRAINER | SUM |
| 4. | KHR2315 | [1] | FUEL HOSE | SUM Superseded by part number: KHR17070 |
| 5. | KHR2316 | [1] | FUEL HOSE | SUM Superseded by part number: KHR17120 |
| 6. | 157710A1 | [1] | COLLAR | SUM |
| 7. | KUR0060 | [1] | BRACKET | SUM |
| 8. | 627-8025 | [3] | BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd | CAS Superseded by part number: 43234 |
| 9. | 895-11008 | [3] | WASHER,M8 x 16 x 1.6 | CAS9 x 17 x 1,6 mm Superseded by part number: 86624184 |
| 10. | 159602A1 | [1] | BOLT,Sems, Hex, M6 x 16mm | SUM |
| 11. | 893-11006 | [1] | LOCK WASHER,Ext Tooth, M6 | CAS Superseded by part number: 86625265 |
| 12. | 168103A1 | [1] | DECAL | SUM |
| 13. | KHJ2320 | [1] | ELBOW | SUM |
| 14. | 157933A1 | [1] | NIPPLE, LUBE | SUM |
| 15. | 166351A1 | [2] | BOLT,Sems, M10 x 20mm | SUM |
| 16. | 157808A1 | [2] | COLLAR | SUM |
