纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (03-011-00[01]) - FUEL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
701 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 41. | 426426A1 | [1] | FILTER ASSY | SUM |
| 107. | 426433A1 | [1] | PIPE | ISU |
| 108. | 289104A1 | [1] | BANJO BOLT | ISU Superseded by part number: 1096750860 |
| 110. | 426423A1 | [2] | GASKET | ISU Superseded by part number: 289094A1 |
| 119. | 426434A1 | [1] | PIPE | ISU |
| 122. | 426435A1 | [1] | PIPE | ISU |
| 123. | 426437A1 | [4] | MOUNTING CLIP | ISU Superseded by part number: 87384507 |
| 124. | 426431A1 | [2] | MOUNTING CLIP | ISU Superseded by part number: 72110435 |
| 125. | 426432A1 | [2] | MOUNTING CLIP | ISU Superseded by part number: 72110436 |
| 126. | 426438A1 | [4] | BOLT | ISUM6 x 30 |
| 131. | 426439A1 | [1] | SUPPORT | ISU |
| 148. | 419935A1 | [2] | BOLT | ISUM8 x 16 Superseded by part number: 76599954 |
