纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (03-017-02[01]) - FUEL INJECTION PUMP - CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
995 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 288531A1 | [1] | SPEED GOVERNOR | ISU |
| 2. | 440253A1 | [1] | HOUSING | ISU |
| 3. | 440260A1 | [8] | BOLT | ISU |
| 5. | 440305A1 | [1] | NUT | ISU |
| 7. | 434211A1 | [1] | COVER | ISU |
| 8A. | 434212A1 | [6] | BOLT | ISU |
| 8B. | 434214A1 | [1] | BOLT | ISU |
| 8B. | 440259A1 | [1] | BOLT | ISU |
| 9. | 289781A1 | [8] | WASHER | ISU |
| 11. | 434215A1 | [1] | GASKET | ISU |
| 123. | 434219A1 | [1] | SEAL | ISU |
| 198. | 444001A1 | [1] | SUPPORT | ISU |
| 213. | 434223A1 | [1] | CIRCLIP | ISU Superseded by part number: 72110761 |
| 308. | 444002A1 | [1] | ANEROID PUMP | ISU |
| 309. | 434225A1 | [2] | BOLT | ISU Superseded by part number: 72110763 |
| 310. | 434226A1 | [1] | BOLT | ISU Superseded by part number: 72110764 |
| 311. | 437860A1 | [1] | GASKET | ISU Superseded by part number: 72110765 |
| 312. | 426423A1 | [2] | GASKET | ISU Superseded by part number: 289094A1 |
| 314. | 440257A1 | [1] | SPRING | ISU |
| 315. | 440255A1 | [1] | SPRING SEAT | ISU |
| 316. | 440256A1 | [1] | SPRING SEAT | ISU |
| 317. | 440311A1 | [1] | ELEC CONNECTOR | ISU |
| 317. | 440312A1 | [1] | ELEC CONNECTOR | ISU Superseded by part number: 72215960 |
| 317. | 440313A1 | [1] | ELEC CONNECTOR | ISU Superseded by part number: 72215961 |
| 318. | 440325A1 | [1] | BOLT | ISU |
| 319. | 440258A1 | [1] | CAP | ISU |
| 320. | 440341A1 | [1] | GASKET | ISU |
| 328. | 444003A1 | [1] | PINION | ISU |
| 331. | 440267A1 | [1] | WASHER | ISU |
| 332. | 440304A1 | [1] | NUT | ISU |
| 342. | 289954A1 | [1] | KEY | ISU |
| 388. | 440251A1 | [2] | BOLT | ISU |
| 477. | 440310A1 | [2] | BUSHING | ISU |
