纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (03-019-00[01]) - FUEL INJECTION PUMP - COUPLING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
309 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 426667A1 | [1] | COUPLING FLANGE | ISU |
| 2. | 426668A1 | [1] | BOLT | ISU |
| 6. | 426669A1 | [1] | COUPLING FLANGE | ISU |
| 7. | 426670A1 | [1] | PLATE, THRUST | ISU Superseded by part number: 72110845 |
| 8. | 426671A1 | [2] | BOLT | ISU |
| 9. | 426672A1 | [2] | BOLT | ISU |
| 10. | 426673A1 | [2] | NUT | ISU |
| 32. | 444030A1 | [1] | DAMPER | ISU |
| 33. | 444031A1 | [1] | BOLT | ISU |
| 34. | 444032A1 | [1] | SUPPORT | ISU |
| 36. | 426674A1 | [1] | COVER | ISU Superseded by part number: 84276619 |
| 41. | 288635A1 | [2] | BOLT | ISUM10 x 60 Superseded by part number: 87601343 |
| 52. | 426675A1 | [1] | SUPPORT | ISU |
