纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (04-009-00[01]) - ELECTRICAL CIRCUIT - OPERATORS COMPARTMENT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
673 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KHR3270 | [1] | IGNITION SWITCH | SUM |
| 2. | KHR3078 | [1] | IGNITION SWITCH | SUM |
| 3. | 150979A1 | [2] | IGNITION KEY | SUM Superseded by part number: KHR20070 |
| 4. | KHR3080 | [1] | CAP | SUM |
| 5. | KHR3081 | [1] | WASHER | SUM |
| 6. | 108R006Y020R | [2] | BOLT | SUMM6 x 20 |
| 7. | 892-11006 | [2] | LOCK WASHER,M6 | CAS Superseded by part number: 86517328 |
| 8. | 159919A1 | [7] | RELAY | SUM |
| 9. | KUP0072 | [1] | LABEL | SUM |
| 10. | 159602A1 | [7] | BOLT,Sems, Hex, M6 x 16mm | SUM |
| 11. | KHR2488 | [1] | LIGHTER, CIGARETTE | SUM |
| 12. | KHR3141 | [1] | PROTECTOR | SUM |
| 13. | KUR0080 | [1] | HARNESS | SUM |
| 14. | 159149A1 | [1] | COLLAR | SUM |
| 15. | 157807A1 | [2] | COLLAR | SUM |
| 16. | 153039A1 | [1] | CLAMP | SUM |
| 17. | 159150A1 | [1] | COLLAR | SUM |
| 19. | 150860A1 | [5] | COLLAR | SUM |
| 20. | 145N006S008R | [5] | SCREW,Pan Hd, M6 x 8mm, Cl 10.9 | SUM |
| 21. | 150067A1 | [6] | MOUNTING CLIP | SUM |
| 22. | KHR2746 | [1] | BRACKET | SUM |
| 23. | KHR2747 | [1] | BRACKET | SUM |
| 24. | KHR2748 | [1] | BRACKET | SUM |
| 25. | 166345A1 | [3] | BOLT | SUM Superseded by part number: 105R008Y016R |
| 26. | KHR2580 | [2] | CLAMP | SUM Superseded by part number: KHR2583 |
| 27. | 159905A1 | [2] | BOLT,Sems, Hex, M6 x 25mm, Spcl | SUM |
| 28. | KHR3181 | [1] | HARNESS | SUM |
| 32. | 157806A1 | [1] | COLLAR | SUM |
| 33. | 156559A1 | [1] | BOLT,High Strength, Hex, M6 x 12mm, W/ LW | SUM |
| 34. | KHR2712 | [1] | HARNESS | SUM |
| 40. | 895-11006 | [4] | WASHER,M6 x 12mm OD x 1.6mm | CAS Superseded by part number: 86588450 |
| 41. | 183-106VR | [4] | SPRING WASHER | SUM |
| 42. | 162R006SR | [4] | NUT | SUMM6 Superseded by part number: 162R006VR |
| 43. | KHR2743 | [1] | CAP COVER | SUM |
| 44. | KHR2913 | [1] | CAP | SUM |
| 45. | KHR3718 | [1] | SWITCH | SUM |
| 46. | KUR0082 | [1] | HARNESS | SUM |
