| .. | YY02B00073F1 | [1] | BOOM | KOBASSY, HOE, Serial Range: YH02-01301-YH02-01335 |
| A1. | NSS | [1] | NOT SOLD SEPARAT | CONBOOM,HOE |
| A1-20A. | 2416T9944 | [2] | BLOCK | KOBTAPPED |
| A1-20B. | 2416T12922 | [2] | BLOCK | KOBTAPPED |
| A1-24. | 2416T27178 | [1] | BLOCK | KOBTAPPED |
| A1-25. | YV02B01006P1 | [1] | BLOCK | KOBTAPPED |
| A1-26. | YV02B01007P1 | [1] | BLOCK | KOBTAPPED |
| A1-27. | 2416T21120D1 | [1] | BLOCK | KOBTAPPED |
| A1-28. | 2416T21120D2 | [1] | BLOCK | KOBTAPPED |
| A1-29. | 2416T9878 | [1] | BLOCK,M10 Thd Hole - 16mm Thk x 32mm W x 60mm L | KOBTAPPED |
| A1-30. | 2416T5710 | [2] | BLOCK | KOBTAPPED |
| A2. | YX05B01026P1 | [2] | BUSHING | KOB Superseded by part number: |
| A2. | YX05B01076P1 | [2] | BUSHING | BUSHING |
| .. | YY02B00157F1 | [1] | BOOM | KOBASSY, HOE, Start Serial: YH02-01336- |
| A1-1. | NSS | [1] | NOT SOLD SEPARAT | CONBOOM, HOE |
| A1-2. | 2416T14732 | [1] | BLOCK | KOBTAPPED |
| A1-3. | YW42H01013P1 | [1] | BLOCK | KOBTAPPED |
| A1-4. | 2416T14115 | [2] | BLOCK | KOBTAPPED |
| A1-5. | YW42H01012P1 | [2] | BLOCK | KOBTAPPED |
| A1-6. | YY02B01094P1 | [1] | BLOCK | KOBTAPPED |
| . . | YX02B00002F1 | [1] | BOOM | KOBBOOM INSTAL |
| B1. | YX02B01002P1 | [1] | PIN | KOB |
| B2. | YX02B01003P1 | [1] | PIN | KOB Superseded by part number: YX02B01003P2 |
| B3. | YX02B01024P1 | [1] | SPRING | KOB |
| B4. | ZW16X18000 | [1] | WASHER | KOBID 18 x OD 34 x Th 3.2mm |
| B5. | B16T0442D57 | [2] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOBID 72 x OD 130 x Th 0.5mm |
| B6. | B16T0442D44 | [2] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOBID 72 x OD 130 x Th 0.9mm |
| B7. | B16T0442D1 | [2] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| B8. | YN12B01009P1 | [2] | SHIM,3mm Thk | KOB(3.0) |
| . . | YY02B00114F1 | [1] | BOOM | KOBGROUP |
| C1. | 2444R1117D084 | [1] | HOSE,6.40mm ID x 840mm L | KOB Superseded by part number: 2444R1117D085 |
| C2. | 2444R1117D088 | [1] | HOSE,6.40mm ID x 880mm L | KOB Superseded by part number: HX21E04090DY |
| C3. | 2444R1117D160 | [1] | HOSE,6.40mm ID x 1600mm L | KOB |
| C4. | HX21E04170DY | [1] | HOSE,6.30mm ID x 1700mm L | KOB1700mm Long (66-59/64 in), Replaces 2444R1117D170 |
| C5. | 2444R1117D230 | [1] | HOSE,6.40mm ID x 2300mm L | KOB |
| C6. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| C7. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| C8. | 2445R138D6 | [2] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| C9. | YY02B01067P1 | [1] | SUPPORT | KOB |
| C10. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| C11. | ZW26X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| . . | YY02B00005F1 | [1] | CYLINDER | KOBINSTAL |
| D1. | LP02B01053P1 | [1] | PIN | KOB |
| D2. | YV02B01011P1 | [2] | PIN | KOB |
| D3. | LP02B01054P1 | [2] | COLLAR | KOB |
| D4. | HS18C14135G2 | [2] | CAPSCREW | KOBSCREW M14x2.0x135mm |
| D5. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| D6. | 2418T21137 | [2] | WASHER | KOB |
| D7. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| D8. | ZN18C14011 | [4] | NUT | KOBM14x2.0mm |
| D9. | LP02B01055P1 | [2] | SHIM,3.0mm Thk | KOB(3.0) |
| D10. | LP02B01060D1 | [2] | SHIM | KOBID 82 x OD 110 x Th 0.5mm |
| D11. | LP02B01060D2 | [2] | SHIM | KOBID 82 x OD 110 x Th 0.9mm |
| D12. | LP02B01060D3 | [2] | SHIM | KOBID 82 x OD 110 x Th 1.2mm |
| D13. | LP02B01060D4 | [2] | SHIM | KOBID 82 x OD 110 x Th 1.6mm |
| D14. | B16T0442D57 | [2] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOBID 72 x OD 130 x Th 0.5mm |
| D15. | B16T0442D44 | [2] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOBID 72 x OD 130 x Th 0.9mm |
| D16. | B16T0442D1 | [2] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| D17. | B16T0442D2 | [2] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| D18. | B16T0442D5 | [2] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOBID 72 x OD 130 x Th 2.3mm |
| . . | YV02B00006F1 | [1] | CYLINDER | KOBINSTAL |
| E1. | YY02B01062P1 | [1] | PIN | KOB |
| E2. | HS18C16140G2 | [1] | SCREW,M16 x 140mm, Cl 10.9 | KOBM16x2.0x140mm |
| E3. | ZN18C16013 | [2] | NUT | KOBM16x2.0mm |
| E4. | B16T0442D44 | [1] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOBID 72 x OD 130 x Th 0.9mm |
| E5. | YN12B01009P1 | [2] | SHIM,3mm Thk | KOB(3.0) |
| E6. | B16T0442D57 | [1] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOBID 72 x OD 130 x Th 0.5mm |
| E7. | B16T0442D1 | [1] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| E8. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
