| 1. | YY01V00001F1 | [1] | CYLINDER ASSY. | KOBBOOM (L.H) Superseded by part number: YY01V00002F2 |
| 2. | YY01V00002F1 | [1] | CYLINDER ASSY. | KOBBOOM (R.H) Superseded by part number: YY01V00002F2 |
| 3. | YY01V00003F2 | [1] | CYLINDER ASSY. | KOBARM Superseded by part number: YY01V00003F5 |
| . . | YY42H00056F1 | [1] | LINE | KOBBOOM |
| A1. | YY42H01235P1 | [1] | TUBE | KOB |
| A2. | YY42H01236P1 | [1] | TUBE | KOB |
| A3. | YY42H01237P1 | [1] | TUBE | KOB |
| A4. | YY42H01238P1 | [1] | TUBE | KOB |
| A5. | ZC26X22011 | [4] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| A6. | 2432T2244 | [2] | CLAMP | KOBDouble -- 102x32x12mm (Ø23xØ23mm) |
| A7. | 2432T2242 | [2] | CLAMP | KOBDouble -- 106x38x12mm (Ø23xØ29mm) |
| A8. | ZS18C10040 | [1] | SCREW,Hex, M10 x 40mm | KOBM10x1.50x40mm |
| A9. | ZS18C10045 | [5] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| A10. | ZS18C12045 | [2] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| A11. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| A12. | ZW26X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| A13. | ZD12A01600 | [6] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| A14. | ZD12A01800 | [2] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| . . | YY42H00003F1 | [1] | LINE | KOBCYLINDER |
| B1. | YY42H01009P1 | [1] | TUBE | KOB |
| B2. | YY42H01010P1 | [1] | TUBE | KOB |
| B3. | YY42H01011P1 | [1] | TUBE | KOB |
| B4. | YY42H01012P1 | [1] | TUBE | KOB |
| B5. | ZX20H10074 | [4] | HOSE | KOB740mm Long (29-1/8 in) |
| B6. | 2432T2244 | [2] | CLAMP | KOBDouble -- 102x32x12mm (Ø23xØ23mm) |
| B7. | ZS18C10045 | [2] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| B8. | ZS28C10030 | [16] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm |
| B9. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| B10. | ZH22Z04000 | [2] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| B11. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| B12. | ZD12A01600 | [4] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| B13. | ZD12P02600 | [4] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| . . | YY42H00004F1 | [1] | LINE | KOBCYLINDER |
| C1. | YY42H01013P1 | [1] | TUBE | KOB |
| C2. | LP02B01011D2 | [1] | HOSE | KOB |
| C3. | ZX20H10080 | [1] | HOSE | KOB800mm Long (31-1/2 in) |
| C4. | YW43H01049P1 | [1] | CLAMP | KOB |
| C5. | ZE13X12000 | [2] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| C6. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| C7. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm |
| C8. | ZS18C10045 | [1] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| C9. | ZS28C10035 | [4] | SCREW,Hex Socket Head, M10 x 35mm | KOBScrew -- M10x1.50x35mm |
| C10. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| C11. | ZD12A01600 | [1] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| C12. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| C13. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| C14. | ZW26K10000 | [4] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
