神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (09-048) - VALVE ASSY, SWING-REACTIONLESS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
601 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX30V00006F1 | [1] | VALVE | KOBASSY, SWING-REACTIONLESS |
| . . | YX30V00006F2 | [1] | VALVE | KOBASSY, SWING-REACTIONLESS |
| . . | YX30V00006F3 | [1] | VALVE | KOBASSY, SWING-REACTIONLESS |
| . . | YX30V00006F4 | [1] | CONTROL VALVE | KOBVALVE ASSY, SWING-REACTIONLESS |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 151. | 2441U722S490 | [4] | PLUG | KOB1/16" NPTF |
| 161. | ZD12P02200 | [2] | O-RING | KOBID 21.80 ± 0.24 x OD 26mm, (FOR F1&F2) |
| 171. | ZS23C08060 | [6] | SCREW,Hex Socket Head, M8 x 60mm | KOBM08x1.25x60mm |
| 401. | YN20V00004S400 | [2] | VALVE | KOBASSY(FOR F1&F3) |
| 402. | YX30V00006S402 | [2] | CONTROL VALVE | KOBASSY(FOR F2&F4) Superseded by part number: LS20V00001S602 |
| 403. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 404. | ZD85P02000 | [2] | RING | KOBBack-Up -- ID 20 x OD 24 x Th 1.25mm |
| 901. | YB15V00003S390 | [1] | PLATE | KOBNAME PLATE |
| 902. | 2437U407S983 | [2] | RIVET | KOBPIN |
| 903. | LQ15V00001S984 | [2] | PLUG | KOB |
| 904. | YZ10V00002S732 | [2] | O-RING | KOB(FOR F3&F4) |
