| 1. |
89837842
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 9837842
|
| 2. |
86620027
|
[2] |
FLANGED BEARING,80.02mm ID x 147.6mm OD x 4mm Thk
|
NH
|
| 3. |
552945
|
[1] |
BEARING ASSY,40 mm ID x 80 mm OD x 30.2 mm
|
NH
Superseded by part number: 412441
|
| 4. |
120044
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 5. |
25817
|
[1] |
OFFSET LINK
|
NNA
Superseded by part number: 3220034R93, 3220034R93, 86595275
|
| 6. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 7. |
84074766
|
[1] |
SHAFT
|
ZED
|
| 7. |
84074764
|
[1] |
SHAFT
|
ZED
|
| 8. |
9706687
|
[3] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 9. |
87681337
|
[1] |
PLATE
|
ZED
|
| 10. |
36403
|
[4] |
BEARING HOUSING
|
GI
Superseded by part number: 578189
|
| 11. |
322360
|
[1] |
BALL BEARING,35mm ID x 72mm OD x 19mm W
|
ZED
|
| 12. |
9837968
|
[1] |
SUPPORT
|
ZED
|
| 13. |
140046
|
[7] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 14. |
100016
|
[8] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 15. |
9837880
|
[1] |
GEAR
|
ZED
|
| 16. |
170026
|
[1] |
KEY
|
ZED
|
| 17. |
9837879
|
[1] |
CHAIN,Roller, 68 Links x 19.05mm = 1295.4mm
|
ZED
(32)
|
| 18. |
120049
|
[1] |
CARRIAGE BOLT,Short Nk, M16 x 90mm, Cl 8.8
|
NH
|
| 19. |
9837878
|
[1] |
SUPPORT
|
ZED
|
| 20. |
378246
|
[4] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 21. |
87517107
|
[3] |
DRIVEN SPROCKET
|
ZED
|
| 22. |
140048
|
[3] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 23. |
100020
|
[3] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 24. |
120046
|
[1] |
CARRIAGE BOLT,M16 x 60mm, Cl 8.8
|
ZED
Superseded by part number: 87552612
|
| 25. |
9837964
|
[1] |
BUSHING,17mm ID x 28mm OD x 13mm L
|
ZED
|
| 26. |
9850764
|
[1] |
PANEL
|
ZED
|
| 27. |
9837966
|
[1] |
CHAIN,Roller, 105 Links x 19.05mm = 2000.25mm
|
ZED
(5, 32)
|
| 28. |
333228
|
[1] |
KEY,10mm W x 8mm H x 40mm L
|
ZED
|
| 29. |
84000091
|
[1] |
DRIVEN SPROCKET
|
ZED
|
| 30. |
43139
|
[3] |
BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
Superseded by part number: 11106231
|
| 31. |
140045
|
[11] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 32. |
165590
|
[1] |
CONNECTING LINK
|
PA
Superseded by part number: 241-1316
|
| 33. |
338949
|
[7] |
CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
|
| 34. |
9837963
|
[1] |
CARRIAGE BOLT,Sq Nk, M16 x 130mm, Cl 8.8
|
ZED
M16 x 130
|
| 35. |
86595275
|
[1] |
OFFSET LINK
|
ZED
Superseded by part number: 241-1716
|
| 36. |
87730562
|
[1] |
SUPPORT
|
ZED
|
| 37. |
86633356
|
[1] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
