| 1. |
86620027
|
[2] |
FLANGED BEARING,80.02mm ID x 147.6mm OD x 4mm Thk
|
NH
|
| 2. |
552945
|
[1] |
BEARING ASSY,40 mm ID x 80 mm OD x 30.2 mm
|
NH
Superseded by part number: 412441
|
| 3. |
9837866
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 84372941
|
| 4. |
36403
|
[2] |
BEARING HOUSING
|
GI
Superseded by part number: 578189
|
| 5. |
9837842
|
[1] |
BEARING,35mm ID x 72mm OD x 19mm W
|
ZED
|
| 6. |
378244
|
[2] |
WASHER,10.5mm ID x 24mm OD x 2mm Thk
|
NH
|
| 7. |
100016
|
[7] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 8. |
120049
|
[2] |
CARRIAGE BOLT,Short Nk, M16 x 90mm, Cl 8.8
|
NH
|
| 9. |
378246
|
[4] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 10. |
140048
|
[2] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 11. |
100020
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 12. |
333228
|
[1] |
KEY,10mm W x 8mm H x 40mm L
|
ZED
|
| 13. |
140045
|
[7] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 14. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 15. |
84007604
|
[2] |
BUSHING,17mm ID x 28mm OD x 29mm L
|
ZED
|
| 16. |
84000092
|
[1] |
DRIVEN SPROCKET
|
ZED
|
| 17. |
86512446
|
[3] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 18. |
87517105
|
[2] |
DRIVEN SPROCKET
|
ZED
|
| 19. |
9850763
|
[1] |
RING
|
ZED
|
| 20. |
9837965
|
[1] |
CHAIN,Roller, 123 Links x 15.88mm = 1952.63mm
|
ZED
(21, 22)
|
| 21. |
25816
|
[1] |
OFFSET LINK
|
GI
Superseded by part number: 86595276
|
| 22. |
25194
|
[1] |
CONNECTING LINK
|
GI
Superseded by part number: 86537460
|
| 23. |
120044
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 24. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 25. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
