纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (06-003-00[01]) - TRAVEL MOTOR AND REDUCTION GEAR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
285 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUA0285 | [2] | WHEEL GEAR | SUM Superseded by part number: KUA10170 |
| 2. | 102R027Y090N | [48] | BOLT | SUMM27 x 90 |
| 3. | 102R027Y100N | [52] | BOLT | SUMM27 x 100 |
| 4. | 157544A1 | [100] | WASHER | SUM |
| 5. | KUA0280 | [2] | MOTO-REDUCTION GEAR | SUM Superseded by part number: KUA10540 |
| 5A. | KUP0071 | [1] | REDUCER | SUM Superseded by part number: KUP10150 |
| 6. | KUA0281 | [1] | REDUCER | SUM Superseded by part number: KUP10150 |
| 7. | KUA0017 | [1] | CASE | SUM |
| 8. | 862-14035 | [60] | HEX SOC SCREW,M14 x 35mm, Cl 12.9 | SUM Superseded by part number: 108R014Y035R |
| 9. | KUA0016 | [1] | BEARING HOUSING | SUM |
| 10. | KUA0020 | [2] | BEARING, BALL | SUM |
| 11. | KUA0030 | [1] | SHIM | SUM |
| 12. | KUA0019 | [1] | RETAINER | SUM |
| 13. | 163918A1 | [1] | PLATE | SUM |
| 14. | KUA0381 | [1] | GEAR SET | SUM Superseded by part number: KUA10520 |
| 15. | KUA0010 | [1] | GEAR, RING | SUM |
| 16. | KUA0005 | [1] | SUN GEAR | SUM |
| 17. | 862-12035 | [32] | HEX SOC SCREW,M12 x 35mm, Cl 12.9 | SUM |
| 18. | KUA0380 | [1] | CARRIER | SUM |
| 19. | KUA0015 | [1] | COVER | SUM |
| 20. | KUA0009 | [1] | GEAR, RING | SUM |
| 21. | KUA0379 | [1] | CARRIER | SUM |
| 22. | KUA0026 | [1] | PLATE, THRUST | SUM |
| 23. | 163924A1 | [1] | RING | SUM |
| 24. | KUA0004 | [1] | SUN GEAR | SUM |
| 25. | KUA0182 | [1] | SUN GEAR | SUM |
| 26. | 800-1150 | [4] | SNAP RING,M50, Ext | CAS Superseded by part number: 8603209 |
| 27. | 163917A1 | [4] | PLATE | SUM |
| 28. | KUA0279 | [4] | GEAR SHAFT | SUM |
| 29. | 163929A1 | [4] | SHIM | SUM0,50 mm (0,019 in) |
| 30. | NSS | [3] | NOT SERVICED SEPARATELY | CON |
| 31. | 152K012Y025B | [2] | SET SCREW | SUMM12 x 25 |
| 35. | 151627A1 | [4] | PIN | SUM |
| 36. | 150829A1 | [3] | PLUG | SUM |
| 43. | KUA0027 | [2] | PLATE, THRUST | SUM |
| 47. | 108R024Y160R | [30] | BOLT | CASM24 x 160 |
| 48. | KUA0018 | [1] | RETAINER | SUM |
| 49. | KUA0022 | [1] | PACKAGE | SUM |
| 50. | 151524A1 | [2] | O-RING | SUM |
| 51. | KUA0282 | [2] | MOTOR, HYDRAULIC | SUM |
| 52. | 150807A1 | [8] | BOLT,Hex Skt, M18 x 2.5 x 50mm | SUM |
