纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (06-007-00[01]) - SWING MOTOR-DRIVE REDUCTION GEAR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
902 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUC0019 | [2] | MOTO-REDUCTION GEAR | SUM |
| 2. | KUC0017 | [1] | MOTOR, HYDRAULIC | SUM |
| 3. | KUP0048 | [1] | REDUCER | SUM |
| 34. | KUC0013 | [2] | PINION | SUM |
| 35. | 150285A1 | [2] | PLATE, LOCKING | SUM |
| 36. | 167069A1 | [2] | WASHER | SUM |
| 37. | 627-16040 | [4] | BOLT,Hex, M16 x 2 x 40mm, Cl 10.9, Full Thd | CAS Superseded by part number: 374835 |
| 38. | 150317A1 | [2] | HEADED PIN,24mm OD x 90mm L | SUM |
| 39. | 166477A1 | [24] | BOLT,Sems, M24 x 90mm | SUM |
| 40. | KHJ1568 | [2] | HYDRAULIC HOSE,12.70 mm ID x 620.00 mm | SUM |
| 41. | KHJ0512 | [1] | HYD CONNECTOR | SUM |
| 42. | 158841A1 | [1] | PLUG | SUM |
| 43. | 157759A1 | [1] | TEE | SUM |
| 44. | 150073A1 | [1] | ADAPTER | SUM |
| 45. | 150602A1 | [1] | ADAPTER | SUM |
| 46. | 150476A1 | [2] | PLASTIC-RUBBER TUBE,19.3 mm ID, 23.8 mm OD, 400 mm Length | SUM Superseded by part number: KHR21050 |
| 47. | 150860A1 | [2] | COLLAR | SUM |
| 48. | 145N006S008R | [2] | SCREW,Pan Hd, M6 x 8mm, Cl 10.9 | SUMM6 x 8 |
| 49. | 150067A1 | [2] | MOUNTING CLIP | SUM150 mm (6 in) |
| 50. | 169346A1 | [2] | GASKET | SUM |
| 51. | 301-1413 | [2] | DRIVE SCREW,Drive, #2 x 3/16" | CAS Superseded by part number: 86542114 |
| 52. | 800-1145 | [2] | SNAP RING,M45, Ext | CAS Superseded by part number: 370007 |
