神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (02-002) - LOW GROUP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
867 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONLOW GROUP |
| . . | YY01F00005F1 | [1] | LOW GROUP | |
| A1. | YN01F01077P1 | [2] | COVER | KOB |
| A2. | YN01F01039P1 | [4] | GUIDE | KOB |
| A3. | 2422T556 | [1] | PLATE | KOB90x50x Th 06mm |
| A4. | 2418T12274 | [1] | PACKING | KOB90x50x Th 05mm -- Rubber |
| A5. | 2420P1580D1 | [16] | SCREW,M18 x 1.5 x 40mm | KOBM18x1.50x40mm |
| A6. | 2420T6786 | [8] | BOLT,M12 x 1.75 x 25mm | KOBM12x1.75x25mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C12025 |
| A7. | ZS18C10014 | [2] | SCREW,Hex, M10 x 14mm | KOBM10x1.50x14mm |
| A8. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| . . | YY02F01065F1 | [1] | COVER ASSY | |
| B1. | YY02F01066P1 | [1] | COVER | KOB |
| B2. | ZW16H12000 | [6] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| B3. | ZS18C12025 | [6] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
