神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (02-003) - JOINT INSTALLATION, SWIVEL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
391 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY19H00003F1 | [1] | JOINT INSTAL, SWIVEL | |
| 1. | 24100J20523F2 | [1] | HYDRAULIC SWIVEL | KOB Superseded by part number: 24100J20523F3 |
| 2. | ZS18F20120 | [1] | SCREW | KOBM20x1.50x120mm |
| 3. | ZS18C12020 | [3] | SCREW,Hex, M12 x 20mm | KOBM12x1.75x20mm |
| 4. | ZN18F20016 | [1] | NUT | KOBM20x1.50mm |
| 5. | ZW16X12000 | [3] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
