神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (02-005[01]) - SLEWING RING ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
674 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LP40F00003F1 | [1] | SLEWING RING | KOBSlewing Assembly, (In-House Product) Superseded by part number: LP40F00003F2 |
| 1. | LP40F00002F1 | [1] | SLEWING RING | KOBSlewing Assembly, Incls. Refs. 1-1 - 1-9 Superseded by part number: LP40F00004F2 |
| 1-1. | LP40F01001P1 | [1] | RACE | KOBOuter Race, Incls. Refs. 1-1A & 1-1B Superseded by part number: LP40F00004F2 |
| 1-1A. | YY40F01010P1 | [1] | Plug | |
| 1-1B. | 2419T1964D7 | [1] | PIN,10mm OD x 56mm L | KOBTaper -- OD 10 x 56mm Long |
| 1-2. | YY40F01008P1 | [1] | RACE | KOBRace, Inner Superseded by part number: YY40F00009F1 |
| 1-3. | 2425T321 | [105] | BALL | KOBØ25.4mm (1 in) Steel |
| 1-4. | YY40F01009P1 | [105] | Retainer | |
| 1-5. | YN40F01024DD | [1] | SEAL | KOBSeal - Used on Assy LP40F00003F1 Superseded by part number: YN40F01024D4 |
| 1-6. | YN40F01024DE | [1] | SEAL | KOBSeal - Used on Assy LP40F00003F1 Superseded by part number: YN40F01024D4 |
| 1-7. | YN22T00194P1 | [1] | TYPE PLATE | KOBName Plate |
| 1-8. | 2420Z1036D3 | [2] | CLEVIS | KOB2.2x4.6mm |
| 1-9. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBStraight |
| 2. | LP53D01001P1 | [36] | BOLT,Hex, M16 x 2 x 45mm | KOB Superseded by part number: LP53D01001P2 |
| .. | LP40F00003F2 | [1] | SLEWING RING | KOBSlewing Ring Assy, (Antex) Incls. Refs. 1 & 2 |
| 1. | LP40F00004F1 | [1] | SLEWING RING | KOBSlewing Assembly, Incls. Refs. 1-1 - 1-9 Superseded by part number: LP40F00004F2 |
| 1-5. | YY40F00011S008 | [1] | SEAL | KOBSeal (Plain Rectangular) - Used on Assy LP40F00003F2 only |
| 1-6. | YY40F00011S009 | [1] | SEAL | KOBSeal - Used on Assy LP40F00003F2 only Superseded by part number: YY40F00011S008 |
