| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY40F00005F1 | [1] | RING ASSY, SLEWING, APPLICABLE No.: YL04-00501--00596, Serial Range: YL04-00501-YL04-00596 | |
| . . | YY40F00005F2 | [1] | SLEWING RING | KOBRING ASSY, SLEWING, APPLICABLE No.: YL05-00597-, Start Serial: YL05-00597 Superseded by part number: YY40F00006F3, LP53D01001P2 |
| 1. | YY40F00004F1 | [1] | RING | KOBRING ASSY, SLEWING, APPLICABLE No.: YL04-00501--00596, Serial Range: YL04-00501-YL04-00596 |
| 1-1. | YY40F01003P1 | [1] | RACE | KOBRACE, OUTER Superseded by part number: YY40F00004F1 |
| 1-1A. | YY40F01003P1001 | [1] | RACE, OUTER | |
| 1-1B. | 2420T4543D2 | [1] | PLUG | KOB |
| 1-1C. | 2419T1964D7 | [1] | PIN,10mm OD x 56mm L | KOBTaper -- OD 10 x 56mm Long |
| 1-2. | YY40F01002P1 | [1] | RACE, INNER | |
| 1-3. | 2425T321 | [108] | BALL | KOBØ25.4mm (1 in) Steel |
| 1-4. | 2425T322 | [108] | RETAINER | KOB |
| 1-5. | 2445P165D6 | [1] | SEAL | KOB Superseded by part number: YN40F01024D4 |
| 1-6. | 2445P165D5 | [1] | SEAL | KOB Superseded by part number: YN40F01024D4 |
| 1-7. | YN22T00191P1 | [1] | PLATE | KOBNAME |
| 1-8. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 1-9. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 2. | LP53D01001P1 | [36] | BOLT,Hex, M16 x 2 x 45mm | KOB Superseded by part number: LP53D01001P2 |
| 3. | YY40F00004F2 | [1] | RING | KOBRING ASSY, SLEWING, APPLICABLE No.: YL05-00597-, Start Serial: YL05-00597 Superseded by part number: YY40F00006F3 |
| 3-2. | YY40F01002P1 | [1] | RACE, INNER | |
| 3-3. | 2425T321 | [108] | BALL | KOBØ25.4mm (1 in) Steel |
| 3-4. | 2425T322 | [108] | RETAINER | KOB |
| 3-5. | 2445P165D6 | [1] | SEAL | KOB Superseded by part number: YN40F01024D4 |
| 3-6. | 2445P165D5 | [1] | SEAL | KOB Superseded by part number: YN40F01024D4 |
| 3-7. | YN22T00191P1 | [1] | PLATE | KOBNAME |
| 3-8. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 3-9. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 3-10. | YY40F01005P1 | [1] | RACE | KOBRACE, OUTER Superseded by part number: YY40F00006F3 |
| 3-10B. | 2420T4543D2 | [1] | PLUG | KOB |
| 3-10C. | 2419T1964D7 | [1] | PIN,10mm OD x 56mm L | KOBTaper -- OD 10 x 56mm Long |
| . . | 2445P114D7 | [1] | SEAL KIT | KOBKIT, CONSISTS OF REF. 1-5, 1-6, 3-5, 3-6 Superseded by part number: YN40F01024D4 |
