凯斯零件查询(LB333P) - BIG RECTANGULAR BALER 'PACKER CUTTER' (9/08-12/12) (13.13[01]) - PACKER CLUTCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
599 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84078683
|
[1] |
CLUTCH
|
ZED
(2 to 16)
|
| 2. |
301624
|
[1] |
SNAP RING,M65, Ext
|
PA
|
| 3. |
84056545
|
[1] |
WASHER
|
ZED
|
| 4. |
615371
|
[2] |
WASHER
|
NH
|
| 5. |
326100
|
[12] |
BOLT,Hex, M10 x 1.5 x 170mm, Cl 8.8
|
ZED
|
| 6. |
84607558
|
[1] |
FLANGE,311mm OD
|
ZED
|
| 7. |
261798
|
[6] |
CLUTCH PLATE,101.6mm ID x 174.6mm OD x 7.11mm Thk
|
NH
|
| 8. |
84056322
|
[6] |
CLUTCH PLATE,101mm ID x 300mm OD
|
ZED
|
| 9. |
84078680
|
[1] |
FLANGE
|
ZED
|
| 10. |
84056319
|
[12] |
BUSHING
|
ZED
|
| 11. |
84056550
|
[1] |
FLANGE
|
ZED
|
| 12. |
84036158
|
[1] |
BUSHING,74.94mm ID x 80mm OD x 20mm L
|
ZED
|
| 13. |
9820493
|
[1] |
WASHER,20.5mm ID x 35mm OD x 2mm Thk
|
ZED
|
| 14. |
322270
|
[12] |
SPRING
|
ZED
|
| 15. |
9832748
|
[12] |
WASHER
|
ZED
Superseded by part number: 140042
|
| 16. |
100016
|
[12] |
NUT,M10 x 1.5, Cl 8
|
NH
|
