纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-005-00[01]) - HYDRAULIC PUMP - COUPLING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
374 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUJ0002 | [1] | FLEXIBLE COUPLING | SUM |
| 2. | KUJ0351 | [1] | PLATE | SUM |
| 3. | KUJ0350 | [1] | PLATE | SUM |
| 4. | 814-12045 | [16] | BOLT,Hex, M12 x 1.75 x 45mm, Cl 8.8 | CAS Superseded by part number: 9628065 |
| 5. | 150811A1 | [16] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 6. | KUJ0309 | [1] | PUMP, HYDRAULIC | SUM Superseded by part number: KUJ11580 |
| 7. | 108R024Y080R | [4] | BOLT | SUMM24 x 80 |
| 8. | 151136A1 | [3] | BUSHING | SUM Superseded by part number: KHJ2620 |
| 9. | 154467A1 | [3] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 10. | 1541849C1 | [3] | COUPLING | IH Superseded by part number: 87026252 |
