纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-007-00[01]) - SUCTION HYDRAULIC CIRCUIT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
478 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUJ0312 | [1] | PIPE ASSY. | SUM |
| 2. | 154721A1 | [1] | O-RING,99.4mm ID x 3.1mm Width | SUM |
| 3. | 862-16035 | [4] | HEX SOC SCREW,M16 x 35mm, Cl 12.9 | CAS |
| 4. | KHJ1923 | [1] | HOSE | SUM |
| 5. | KHJ1261 | [4] | CLAMP | SUM |
| 6. | KUJ0313 | [1] | PIPE ASSY. | SUM |
| 7. | 152078A1 | [1] | U-BOLT,M12 x 116mm W x 133mm L | SUM |
| 8. | 150811A1 | [2] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 9. | 162R012VR | [2] | NUT | SUMM12 |
| 10. | KHJ1943 | [1] | HYDRAULIC HOSE | SUM |
| 12. | KUJ0145 | [1] | HYD. TUBE,93.2 mm ID x 101.6 mm OD | SUM |
| 13. | 154733A1 | [1] | O-RING | SUM |
| 15. | 162659A1 | [1] | PLUG | SUM |
| 16. | 152211A1 | [1] | O-RING | SUM Superseded by part number: 154523A1 |
| 17. | 162335A1 | [1] | PLUG | SUM |
