| 1. |
84074197
|
[1] |
SUPPORT
|
ZED
|
| 2. |
43168
|
[12] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 3. |
80394631
|
[1] |
WASHER
|
ZED
16 MM Superseded by part number: 394631
|
| 5. |
86000441
|
[1] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 7. |
80043127
|
[1] |
SCREW,M8 x 25mm
|
ZED
Cap, HH, CL 8.8, M8 x 1.25 x 25 Superseded by part number: 43127
|
| 8. |
84053391
|
[4] |
CARRIAGE BOLT,Short NK, M12 x 130, Cl8.8
|
ZED
|
| 9. |
84038871
|
[1] |
SUPPORT
|
ZED
|
| 10. |
87682542
|
[1] |
GUIDE
|
ZED
|
| 11. |
84038868
|
[1] |
ROD
|
ZED
|
| 12. |
300423
|
[2] |
COTTER PIN,M6.3 x 50
|
WIN
|
| 13. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 14. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 15. |
43138
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 16. |
84818579
|
[1] |
SHAFT
|
ZED
|
| 17. |
84073277
|
[1] |
PLATE
|
ZED
|
| 18. |
120038
|
[2] |
CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 811-8030
|
| 19. |
43140
|
[2] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 20. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 21. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 22. |
338949
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
|
| 23. |
84801004
|
[1] |
SUPPORT
|
ZED
(30)
|
| 24. |
84078470
|
[1] |
PLATE
|
ZED
|
| 25. |
86507486
|
[1] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 25. |
86512443
|
[1] |
CARRIAGE BOLT,Sht Nk, M8 x 35mm, Cl 8.8, Full Thd
|
ZED
|
| 26. |
84607491
|
[7] |
PLATE
|
ZED
|
| 27. |
84069248
|
[70] |
RIVET,Pop, 4.8mm OD x 20.7mm L
|
ZED
RIVET
|
| 28. |
84607487
|
[7] |
STIFFENER
|
ZED
|
| 29. |
84004713
|
[1] |
BUSHING,10.5mm ID x 25mm OD x 18mm L
|
ZED
|
| 30. |
84068687
|
[4] |
SCRAPER BLADE
|
ZED
|
| 31. |
86511324
|
[1] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 32. |
9706685
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
