神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (02-009) - IDLER ADJUST ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
556 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN54D00010F2 | [1] | IDLER | KOB Superseded by part number: YN54D00011F2 |
| 1. | YN70V00006P1 | [1] | GREASE | KOB |
| 2. | YN54D01041P1 | [1] | BRACKET | KOB Superseded by part number: YN54D01051P1 |
| 3. | YN54D01038P1 | [1] | NUT | KOBM52x3.0mm |
| 4. | ZP26D08080 | [1] | PIN | KOBRoll -- OD 08 x 80mm Long |
| 6. | 2439P177 | [1] | PISTON | KOB |
| 7. | YN54D01042P1 | [1] | COLLAR | KOBCOLLAR |
| 8. | ZD12G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOBID 79.40 ± 0.69 x OD 85mm |
| 9. | 2418U130D35 | [1] | PACKING | KOBOIL SEAL |
| 10. | LQ54D01023P1 | [2] | PIN | SM |
| 11. | YN54D01029P1 | [1] | COVER | KOB |
| 12. | YN54D01043P2 | [1] | SPRING | KOB Superseded by part number: YN54D01044P1 |
