神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (02-016) - HYD LINES, PROPEL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
432 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN12H00005F1 | [1] | HYD LINES, PROPEL | |
| 1. | HG24F12016G1 | [4] | HYD CONNECTOR | KOB |
| 2. | ZH22X08000 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 3. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 4. | ZD12A01800 | [4] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
