神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (02-017[00]) - DOZER ASSEMBLY (YY51BU0003F1 & YY51BU0003F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
733 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY51BU0003F1 | [1] | DOZER BLADE | SMDozer Assembly Superseded by part number: YY51BU0003F2 |
| . . | YY51BU0003F2 | [1] | DOZER BLADE | KOBDozer Assembly |
| 1. | YY51BU1021F1 | [1] | ARM | KOB |
| 5. | YY51B01043F1 | [1] | LINK | KOB |
| 8. | YY51BU1096P1 | [1] | BRACKET | KOBTrunion Ball Assembly with Mounting Bracket |
| 8. | YY51B01038P1 | [1] | CAP | KOBAttaches to Bracket |
| 8. | YY51BU1032P1 | [1] | BRACKET | KOBMounting, (Welded to Blade) |
| 11. | YY51B01050P1 | [2] | RETAINER | KOB |
| 12. | YY51B01052P1 | [2] | SHIM | KOB(4.5) |
| 13. | YY51B01053P1 | [8] | SHIM | KOB(0.8), (F1 Only) |
| 16. | ZS18C16045 | [2] | SCREW,Hex, M16 x 45mm | KOBM16x2.0x45mm |
| 17. | YY51B01054P1 | [4] | SCREW | KOB7/8"-9UNC x 140mm Long |
| 20. | ZW16H16000 | [2] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 21. | ZW16H22000 | [4] | WASHER | KOBID 23 x OD 44 x Th 6.0mm |
| 22. | YY63TU1001F1 | [1] | BLADE | SMBlade Assembly (F1 Only) -- See Figure 02-017-01 |
| 23. | YY63TU1001F2 | [1] | BLADE | SMBlade Assembly (F2 Only) -- See Figure 02-017-01 |
