凯斯零件查询(LB333P) - BIG RECTANGULAR BALER 'PACKER CUTTER' (9/08-12/12) (13.35[01]) - PICK-UP, MAIN TRANSMISSION - CLUTCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
484 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87732056
|
[1] |
SPACER
|
ZED
Superseded by part number: 84270312
|
| 2. |
NSS
|
[3] |
NOT SOLD SEPARAT
|
CON
|
| 3. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 4. |
120069
|
[8] |
BOLT,M10 x 1.5 x 56.58mm OAL, Cl 8.8
|
NH
|
| 5. |
100037
|
[8] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 6. |
87731730
|
[1] |
PLATE
|
ZED
, Serial Range: -C869 Superseded by part number: 87565205
|
| 6. |
87565205
|
[1] |
PLATE
|
BEL
, Start Serial: D870
|
| 8. |
87731708
|
[2] |
DISC
|
ZED
, Serial Range: -C869 Superseded by part number: 87565196
|
| 8. |
87565196
|
[2] |
DISC
|
BEL
, Start Serial: D870
|
| 9. |
87731760
|
[1] |
LOCKING PLATE
|
ZED
|
| 10. |
87731756
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 84004298
|
| 11. |
87732109
|
[1] |
FLANGE
|
ZED
|
| 12. |
87732110
|
[1] |
HUB
|
ZED
|
| 13. |
87731721
|
[1] |
PLATE
|
ZED
Superseded by part number: 47362906
|
| 14. |
87731755
|
[1] |
BELLEVILLE SPRING
|
ZED
|
| 15. |
87732111
|
[1] |
CLUTCH HOUSING
|
ZED
|
| 16. |
87731710
|
[1] |
RING
|
ZED
Superseded by part number: 87565207
|
| 17. |
87364750
|
[1] |
CLUTCH
|
ZED
(1 to 16, 18)
|
| 18. |
84004498
|
[1] |
REPAIR KIT
|
ZED
(2, 7)
|
