凯斯零件查询(LB333P) - BIG RECTANGULAR BALER 'PACKER CUTTER' (9/08-12/12) (13.33[01]) - SHUTTLE FEEDER, CLUTCH, LH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
789 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87748631
|
[1] |
CLUTCH
|
ZED
(2 to 17)
|
| 2. |
87748632
|
[1] |
FEEDER
|
ZED
|
| 3. |
84056050
|
[1] |
BALL BEARING,20mm ID x 52mm OD x 20.6mm W
|
ZED
|
| 4. |
370024
|
[1] |
CIRCLIP,M20, Ext
|
NH
|
| 5. |
84806271
|
[1] |
SHAFT,27.89mm OD x 91mm L
|
ZED
|
| 6. |
87327625
|
[1] |
DOG
|
ZED
Superseded by part number: 87327626
|
| 7. |
84058620
|
[1] |
PIN,20mm OD x 62mm L
|
ZED
|
| 8. |
301644
|
[1] |
CIRCLIP,M30, Int
|
COE
|
| 9. |
84400783
|
[1] |
ROLLER
|
ZED
|
| 10. |
300868
|
[1] |
ROLL PIN,6mm OD x 36mm L, Slotted
|
NH
|
| 11. |
84806601
|
[1] |
SPRING,Extension, 28.399mm OD x 108mm L
|
ZED
|
| 12. |
673
|
[1] |
WASHER,29mm ID x 41mm OD x 1.52mm Thk
|
NH
|
| 13. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 14. |
87531836
|
[1] |
EXTENSION
|
ZED
|
| 15. |
120259
|
[2] |
HEX SOC SCREW,CSS, M10 x 40mm, Cl 10.9
|
ZED
|
| 16. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 17. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
