神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (02-019[00]) - DOZER INSTALLATION (YY51BU0001F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
616 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY51B01055P1 | [2] | PIN | KOBOD 70 x 266mm Long |
| 2. | ZS18C16130 | [4] | CAPSCREW,Hex, M16 x 130mm | KOBSCREW M16x2.0x130mm |
| 3. | ZN18C16013 | [8] | NUT | KOBM16x2.0mm |
| 4. | 2445R138D6 | [4] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| 5. | B16T0442D1 | [2] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| 6. | YY51BU1007P1 | [2] | PIN | KOBOD 63.4 x 292mm Long |
| 9. | YY51BU1070P1 | [6] | SHIM | KOB(1.6) |
