凯斯零件查询(LB333P) - BIG RECTANGULAR BALER 'PACKER CUTTER' (9/08-12/12) (14.09[01]) - FIXED KNIFE AND HAY-DOGS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
553 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84429747
|
[1] |
GUIDE
|
ZED
|
| 2. |
84400465
|
[1] |
KNIFE
|
ZED
|
| 2. |
84814537
|
[1] |
KNIFE,630mm L x 60mm W x 10mm Thk
|
ZED
|
| 3. |
84800581
|
[5] |
GUIDE
|
ZED
|
| 4. |
84800583
|
[5] |
GUIDE
|
ZED
|
| 5. |
84607550
|
[6] |
GUIDE
|
ZED
|
| 6. |
84814538
|
[1] |
KNIFE,540mm L x 60mm W x 10mm Thk
|
ZED
|
| 7. |
84429787
|
[1] |
GUIDE
|
ZED
|
| 8. |
328754
|
[36] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 9. |
140046
|
[36] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 10. |
9706685
|
[43] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 11. |
86629541
|
[6] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
, Serial Range: -C885
|
| 11. |
120080
|
[6] |
BOLT,Hex, M12 x 45, 8.8
|
PA
, Start Serial: D886 Superseded by part number: 9628065
|
| 12. |
380420
|
[7] |
BOLT
|
NH
|
| 13. |
84021078
|
[2] |
COVER
|
ZED
|
| 14. |
322357
|
[5] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 15. |
84814892
|
[4] |
WING NUT,M6 x 1.0
|
ZED
|
| 16. |
87600336
|
[1] |
PLATE
|
ZED
|
| 17. |
86512439
|
[1] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 18. |
9706755
|
[1] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 19. |
87376144
|
[13] |
WASHER,13mm ID x 28mm OD x 5mm Thk
|
FLX
, Start Serial: D870
|
