| 1. |
84100796
|
[4] |
ROLLER,72mm OD x 29mm L
|
ZED
|
| 2. |
84441748
|
[4] |
SUPPORT
|
ZED
|
| 3. |
84814847
|
[3] |
SHAFT
|
ZED
|
| 4. |
84814846
|
[1] |
SHAFT
|
ZED
|
| 5. |
84800679
|
[1] |
PLUNGER
|
ZED
Superseded by part number: 394632, 84470773, 84488254, 84469721, 84498844, 84498751, 84470780, 47470788
|
| 5. |
84817022
|
[1] |
PLUNGER
|
ZED
Superseded by part number: 84498844, 84498751, 84470769, 84470767, 394632, 47470788, 84488254, 84469719
|
| 5. |
84442120
|
[1] |
PLUNGER
|
ZED
Superseded by part number: 394632, 47470788, 84470780, 84469718, 84498844, 84498751, 84470773, 84488255
|
| 5. |
84817021
|
[1] |
PLUNGER
|
ZED
Superseded by part number: 84498844, 84498751, 84488255, 394632, 84470767, 47470788, 84469708, 84470769
|
| 6. |
84441921
|
[2] |
SUPPORT
|
ZED
|
| 7. |
84441749
|
[1] |
CAM
|
ZED
|
| 8. |
861325
|
[2] |
BEARING ASSY,0.75" ID x 2.5" OD x 2.25"
|
NH
|
| 9. |
140046
|
[5] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 10. |
300388
|
[4] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 11. |
100033
|
[4] |
THIN NUT,Thin, M24 x 1.5, Cl 04
|
ZED
|
| 12. |
9838305
|
[4] |
WASHER,26mm ID x 38mm OD x 2.27mm Thk
|
ZED
|
| 13. |
140048
|
[4] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 14. |
392530
|
[4] |
NUT,M16, Cl 10
|
NH
|
| 15. |
322359
|
[2] |
BELLEVILLE WASHER,M20 Bolt Size x 40mm OD x 3.2mm Thk
|
NH
|
| 16. |
1689
|
[2] |
NUT,3/4"-16, G5
|
NH
Superseded by part number: 80001689, 80001689, 87508272
|
| 17. |
412185
|
[4] |
CARRIAGE BOLT,Short Sq Nk, M16 x 2 x 50mm, Cl 8.8, Full Thd
|
DUB
, Serial Range: -C823
|
| 17. |
84441255
|
[4] |
CARRIAGE BOLT,Sq Nk, M16 x 2 x 50mm, Cl 10.9
|
ZED
, Start Serial: D824
|
| 18. |
9706685
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 19. |
374895
|
[1] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 20. |
543043
|
[1] |
WASHER,13mm ID x 35mm OD x 2.5mm Thk
|
NH
|
| 21. |
84064578
|
[4] |
BUSHING,16.5mm ID x 32mm OD x 12.5mm L
|
ZED
|
