| 1. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 2. |
9838862
|
[2] |
SPRING
|
ZED
|
| 3. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 4. |
9838366
|
[1] |
ROLLER,32mm OD x 40mm L
|
ZED
|
| 5. |
84014757
|
[1] |
BUSHING,12mm ID x 25mm OD x 14mm L
|
ZED
|
| 6. |
84400783
|
[1] |
ROLLER
|
ZED
|
| 7. |
84021161
|
[1] |
SET SCREW,M8 x 12mm
|
ZED
|
| 8. |
84100887
|
[1] |
ARM
|
ZED
|
| 9. |
84814919
|
[2] |
SET SCREW,M12 x 20mm, Cl 8.8
|
ZED
|
| 10. |
9838854
|
[1] |
KEY
|
ZED
|
| 11. |
87668702
|
[1] |
SHAFT
|
ZED
Superseded by part number: 87668703
|
| 11. |
87653427
|
[1] |
SHAFT
|
ZED
Superseded by part number: 87653426
|
| 12. |
87665393
|
[1] |
PLATE
|
ZED
|
| 13. |
84801036
|
[1] |
ARM
|
ZED
|
| 14. |
9838844
|
[1] |
SHAFT
|
ZED
|
| 15. |
84806601
|
[1] |
SPRING,Extension, 28.399mm OD x 108mm L
|
ZED
|
| 16. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 17. |
300868
|
[1] |
ROLL PIN,6mm OD x 36mm L, Slotted
|
NH
|
| 18. |
84058620
|
[1] |
PIN,20mm OD x 62mm L
|
ZED
|
| 19. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 20. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 21. |
9837806
|
[1] |
FLANGED BEARING,25mm ID
|
ZED
|
| 22. |
84817518
|
[1] |
BALL BEARING,25mm ID x 47mm OD x 12mm W
|
ZED
|
| 23. |
87668703
|
[1] |
SHAFT
|
ZED
(3 to 5, 11, 24 to 27)
|
| 23. |
87653426
|
[1] |
SHAFT
|
ZED
(3 to 5, 11, 24 to 27)
|
| 24. |
9838237
|
[6] |
HEX SOC SCREW,CSS, #10 - 32 x 1/2"
|
ZED
|
| 25. |
87521132
|
[6] |
ROPE GUIDE ROLLER,31.5mm OD x 12mm L
|
ZED
Superseded by part number: 47508395
|
| 26. |
84607927
|
[6] |
SCREW,#10 - 32 x 0.55",
|
ZED
|
| 27. |
399555
|
[1] |
THIN NUT,Thin, M12 x 1.5, Cl 04
|
ZED
|
| 28. |
86512443
|
[2] |
CARRIAGE BOLT,Sht Nk, M8 x 35mm, Cl 8.8, Full Thd
|
ZED
|
| 29. |
9838835
|
[2] |
SHIM,57.15mm ID x 76.2mm OD x 0.25mm Thk
|
ZED
|
| 30. |
9838834
|
[3] |
SHIM,57.15mm ID x 76.2mm OD x 0.8mm Thk
|
ZED
|
| 31. |
327911
|
[1] |
CIRCLIP,55mm ID
|
BHB
|
| 32. |
87666776
|
[1] |
HOUSING
|
ZED
|
| 33. |
120068
|
[2] |
BOLT,Hex, M10 x 40mm, Cl 8.8
|
NH
|
| 34. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
