| 1. |
374895
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 2. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 3. |
327911
|
[4] |
CIRCLIP,55mm ID
|
BHB
|
| 4. |
853175
|
[2] |
FLANGE
|
ZED
Superseded by part number: 76450
|
| 5. |
9838774
|
[1] |
BALL BEARING,55.56mm ID x 100mm OD x 25mm W
|
ZED
|
| 6. |
87519491
|
[12] |
SHIM,57.15mm ID x 76.2mm OD x 0.8mm Thk
|
ZED
|
| 7. |
9838867
|
[12] |
DRIVE SCREW,Rd Hd, #10 x 1/2", U Type
|
ZED
|
| 8. |
9838865
|
[6] |
SPACER
|
ZED
|
| 9. |
84019174
|
[6] |
CAM
|
ZED
|
| 10. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 11. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
62161
|
[1] |
LUBE NIPPLE,M8 x 1.25, Str
|
NH
|
| 13. |
87645415
|
[6] |
KEY
|
ZED
, Serial Range: -C823
|
| 13. |
412077
|
[6] |
KEY
|
ZED
, Start Serial: D824
|
| 14. |
84814780
|
[1] |
SUPPORT
|
ZED
(29, 50)
|
| 15. |
87692029
|
[1] |
BUSHING,58.5mm ID x 76.1mm OD x 60.8mm L
|
ZED
|
| 16. |
9838826
|
[6] |
PIN,12.7mm OD x 28.57mm L
|
ZED
|
| 17. |
9838827
|
[6] |
COTTER PIN
|
ZED
|
| 18. |
86512446
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 19. |
9838753
|
[1] |
KEY
|
ZED
|
| 20. |
87668106
|
[1] |
CAM
|
ZED
|
| 21. |
87727572
|
[1] |
JOINING ELEMENT
|
ZED
, Serial Range: -C895 Superseded by part number: 84473995
|
| 21. |
84473995
|
[1] |
SPLINED COUPLING
|
ZED
, Start Serial: D896
|
| 22. |
87667865
|
[1] |
CAM
|
ZED
|
| 22. |
87667867
|
[1] |
CAM
|
ZED
|
| 23. |
412151
|
[3] |
BOLT,M10 x 1.5 x 61.58mm, Cl 8.8
|
NH
Superseded by part number: 73161469
|
| 24. |
87645412
|
[4] |
BUSHING,58.5mm ID x 76.1mm OD x 28.5mm L
|
ZED
|
| 24. |
87665384
|
[2] |
BUSHING
|
ZED
|
| 25. |
87645414
|
[1] |
BUSHING,58.5mm ID x 76.1mm OD x 11.5mm L
|
ZED
, Serial Range: -C823
|
| 25. |
84165514
|
[1] |
BUSHING,58.5mm ID x 76.1mm OD x 10mm L
|
ZED
, Start Serial: D824
|
| 26. |
87653414
|
[1] |
SHAFT
|
ZED
|
| 26. |
87665382
|
[1] |
SHAFT
|
ZED
|
| 27. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 28. |
87519492
|
[24] |
SHIM,56mm ID x 72mm OD x 0.2mm Thk
|
ZED
|
| 29. |
9838824
|
[1] |
BRONZE BUSHING
|
ZED
|
| 31. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 32. |
84022935
|
[6] |
SET SCREW,Hex Soc, M8 x 8
|
ZED
|
| 33. |
87658854
|
[1] |
BELLCRANK
|
ZED
|
| 34. |
87665470
|
[1] |
BRAKE DISC
|
ZED
|
| 36. |
43140
|
[3] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 37. |
9837743
|
[3] |
KIT,56mm ID x 70.3mm OD x 2mm Thk
|
ZED
|
| 38. |
9838835
|
[8] |
SHIM,57.15mm ID x 76.2mm OD x 0.25mm Thk
|
ZED
|
| 39. |
9838834
|
[4] |
SHIM,57.15mm ID x 76.2mm OD x 0.8mm Thk
|
ZED
|
| 40. |
87660400
|
[2] |
BRAKE SHOE
|
ZED
|
| 41. |
87663943
|
[2] |
CARRIAGE BOLT,Sq Nk, M10 x 1.5 x 75mm, Cl 8.8
|
ZED
|
| 42. |
320502
|
[3] |
SPRING
|
ZED
|
| 43. |
84005615
|
[2] |
WASHER,10.5mm ID x 32mm OD x 2mm Thk
|
ZED
|
| 44. |
87661858
|
[1] |
BRACKET, SUPPORTING
|
ZED
|
| 45. |
300381
|
[1] |
BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8
|
NH
Superseded by part number: 412479, 412479, 614-8035
|
| 46. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 47. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
