神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (05-003) - SUN VISOR ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
533 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT55C00001F1 | [1] | SUN VISOR | KOBASSY Superseded by part number: YT55C00002F1 |
| . . | YT55C00001F2 | [1] | SUN VISOR | KOBASSY |
| 1. | YT55C00002F1 | [1] | SUN VISOR | KOB(F1 ONLY) |
| 1-1. | YT55C00002S001 | [1] | SUN VISOR | KOB Superseded by part number: YT55C00002F1 |
| 1-2. | YT55C00002S002 | [1] | ADHESIVE | KOB |
| 1-3. | YT55C00002S003 | [6] | SPACER | KOB |
| 1-4. | YT55C00002S004 | [6] | WASHER | KOB |
| 1-5. | YT55C00002S005 | [6] | SCREW | KOBTAPPING |
| 2. | YT55C01001F1 | [1] | GUTTER | KOBRAIN (F2 ONLY) |
| 2-1. | YT55C01001S001 | [1] | GUARD | KOB |
| 2-2. | YT55C01001S002 | [1] | SEAL | KOB |
| 2-3. | YT55C01001S003 | [1] | ADHESIVE | KOB Superseded by part number: YT55C01001F1 |
| 2-4. | YT55C01001S004 | [1] | ADHESIVE | KOB Superseded by part number: YT55C01001F1 |
| 2-5. | YT55C01001S005 | [1] | ADHESIVE | KOB Superseded by part number: YT55C01001F1 |
| 2-6. | YT55C01001S006 | [5] | SPACER | KOB |
| 2-7. | YT55C01001S007 | [5] | WASHER | KOB |
| 2-8. | YT55C01001S008 | [3] | SCREW | KOBTAPPING |
